Manufacturer: Whelen

L41 Series beacons are certified SAE Class 1 with 25 flash patterns. Ultra High Intensity LED technology rivals strobe in intensity and draws far less power. LED light source has a rated life that exceeds that of strobe flash tubes by more than 50:1

FEATURES

  • SAE Class 1 certified
  • Medium profile, smooth outer dome, universal application.
  • Encapsulated electronics for moisture and vibration resistance.
  • 50,000 hour rated life.
  • Virtually no EMI radiation.
  • LED beacon design features 75 SignalAlert™ flash patterns, per minute, standard.
  • Permanent mount model allows for permanent flat mount, J-Hook mount, or 1” NPT pipe mounting. Supplied with five wire, 6” pigtail (Hi/Low, Scan-Lock™ and sync wire).
  • Magnetic and magnetic/suction mount models supplied with 10’ straight cord and cigar plug with LED indicator On/Off switch plus pattern control switch.
  • 25 total selectable flash patterns (including steady-burn).
  • Polycarbonate dome.
  • Cast aluminum powder coated base.
  • Permanent mount available with photocell Hi/Low – contact factory.

SPECIFICATIONS

  • 12/24 VDC operation
  • 12V- peak 1.5A/avg. 0.6A
  • 24V- peak 0.75/avg. 0.3A
  • Five year HDP Heavy Duty Professional warranty



MODEL

MODELDESCRIPTION
L41 AMAmber, Magnetic Mount (stock item)
L41 APAmber, Perm/Pipe Mount (stock item)
L41 *M/P*Blue, Clear/White, Red, or Green available (special order)
