Manufacturer: Wanco®


The new Wanco radar-speed trailer with full-matrix display features the largest portable speed sign available today. Visible over a standard Jersey barrier traffic divider, the giant display shows motorists’ speed in 26-inch characters, warning motorists to slow down by flashing their excessive speed.


Commonly deployed in school zones, neighborhoods and high-accident areas, numerous options provide a strong measure of traffic calming unmatched by other roadway signs. Wanco engineers designed the new full-matrix radar-speed display to be the largest, most visible display on the market. The compact, portable trailer is intended for use in neighborhoods and alongside highways. When a motorist exceeds the speed limit, the display flashes the vehicle’s speed. For excessive speed, a selectable overspeed message flashes slow down or a frowning face symbol, together with optional flashing red-and-blue “police” lights that attract attention. Factory-configured units show motorists’ speed in mph (one or two digits) or km/h (up to three digits — see international model). A regulatory sign above the display features changeable speed-limit numbers for easy setup in any speed zone. The speed-limit sign and electronic display rotate to face traffic. The display’s LEDs have visors and shades that produce superior angularity and visibility. The trailer’s see-through design puts pedestrians in view, improving their safety—particularly in dangerous, high-risk areas. The solar-powered battery-charging system provides longer run times.


  • Extra-large full-matrix display
  • Optical lenses and sun shades over 26-inch LED characters
  • Selectable speed-limit setting
  • Clearly displays speed in mph (one or two digits) or km/h (up to three digits —see international model)
  • Software-controlled selection of speed units, mph or km/h
  • 24x30-inch regulatory speed-limit sign included, other sizes available
  • Regulatory sign has changeable speed-limit numbers
  • Approach-only K-band radar measures speeds from 5 to 150 mph (8 to 240 km/h), at a distance of up to 1500 feet (450 meters)
  • Radar unit is CE compliant, FCC approved
  • Extended height increases visibility
  • Streamlined see-through design
  • Compact and easily portable, 5-minute setup
  • Under 900 pounds (400kg), can be towed by most vehicles
  • Standard 2-inch ball coupler tow-hitch
  • Regulatory speed-limit sign
  • Battery powered & solar charging
  • Locking control box and battery compartment



dimensions radar speed trailer

























Approx. 870 lbs



Trailer: MIG-welded steel tubing

Speed-display cabinet: Aluminum sheet construction, NEMA 4 rated

Coating: Powder-coated and oven-baked

Sign: Aluminum sheet

Tires: ST25/75D13



Batteries: Two Group 24 deep-cycle 6 V dc batteries for 12 V dc power supply; four batteries optional

Battery capacity: 215 Ah total

Solar panel: One 65 W panel; higher-output panels optional


Regulatory Sign

Size: 24x30 inches standard, 36x36 inches optional


Optional traffic data collector

Technology: Radar-based, no loops or hoses

Count: Counts both approaching and departing vehicles, records speed, direction, length, date and time

Range: Adjustable up to 700 ft
